Online Seminar (with costs): Strain Gauge Measurement Online Seminar (with costs): Strain Gauge Measurement | HBM

Online-Seminar: Measuring with Strain Gauges - Planning, Performing and Evaluating (DM)



 3 hours online training (4x)



  from your PC



  Level: Advanced



 Check Pricing

In this advanced online course to become a strain gauge measurement professional, we will teach you how to perform correct measurements with strain gauges. Learn about the correct compensation of temperature effects, different connection variants of strain gauges, and much more. By completing this seminar, you will gain confidence in instrumentation and performing of measurements with strain gauges. Our trainers will teach you online and will be available for all your questions.

Day 1

Day 2

Day 3

Day 4

Wheatstone Bridge & Compensation I

Connection & Compensation II

Strain Gauge Amplifiers

Strain, Stress and Hooke's Law

• Fundamentals

• Compensation of different influences

• Temperature Compensation I

• Demonstration experiments and discussion

• Connection options (2-/3-/4- etc. wirering)

• Self-compensation strain gauges

• Temperature Compensation II

• Demonstration experiments and discussion

• Amplifier principles (CF, DC)

• Selection criteria

• Eliminate undesirable influences

•Additional functions

• Demonstration experiments and discussion

• Load, residual stress and thermal stress

• Uniaxial and multi-axial stress

• Determination of principal stress states

• Demonstration experiments and discussion

Your HBK Academy-Plus

Also, in our online seminars you can expect a balanced mix with theory and a lot of practical examples. In the theoretical part you will acquire the necessary knowledge. And, in many demonstration experiments, as well as in exchange with the trainer and the group you will consolidate what you have learned. Discussions are appreciated!


Target group:

All those who want to plan, execute, or evaluate strain gauge measurements on their own and know what they are doing.


Prior knowledge:

Knowledge of installing strain gauges.


Upcoming question for technical requirements will be answered here.
Please contact us if there are further question!

Available Dates (please note: this is a seminar for which we charge a fee!)

Sep 26 - 29, 2023 Online
Event registration

Individual Date on Request
Event registration



Start and End Time:
08:30 – 12:00 New York (ET)
14:30 – 18:00 Berlin (CET/CEST)



Duration: on 4 consecutive days / 3,5 hours parts
(with a scheduled break in between!)

price: 1080 EUR exclusive VAT // $1,344 USD


Individual support

Our Academy team is happy to assist!
  0049-(0)6151/803-8061
  [email protected]
