PMXデータ収集・制御システム： テストベンチおよび生産用

The HBM Common API enables users to develop their own PC software application, integrating DAQ systems like QuantumX, SomatXR, PMX and MGCplus.

The download includes the free of charge API as well as documentation and example programs in C#.

Date: 05/2024  |  Version: 6.3  |  Size: 29 MB
関連情報: Release Notes

The driver allows to integrate QuantumX, SomatXR, PMX and MGCplus in DIAdem (32 and 64 Bit). Only available in German language. Please see the Release Note for further details and requirements. The download can be used 30 days as trial. To unlock the license, a license key must be purchased.

Date: 03/2024  |  Version: 1.4.0  |  Size: 67 MB
関連情報: Release Notes

The driver allows to integrate QuantumX, SomatXR, PMX and MGCplus in LabVIEW. Please see the Release Notes for further details and requirements. The download can be used 30 days as trial. To unlock the license, a license key must be purchased.

Date: 02/2021  |  Version: 4.0  |  Size: 24 MB
関連情報: Release Notes

The driver allows to integrate QuantumX, SomatXR, PMX and MGCplus in LabVIEW. Please see the Release Notes for further details and requirements. The download can be used 30 days as trial. To unlock the license, a license key must be purchased.

Date: 02/2021  |  Version: 4.0  |  Size: 24 MB
関連情報: Release Notes

The driver allows to integrate PMX into Matlab. It includes also an executable example.

Matlab has to be already installed.

This example does not imply any warranty or guarantee.

Date: 09/2019  |  Version: 1.0  |  Size: 919 KB

PMX device description file for Ethernet/IP.

Date: 02/2015  |  Version: 0.24  |  Size: 62 KB

PMX device description files for ProfiNet RT and IRT.

Date: 02/2015  |  Version: 2.3  |  Size: 84 KB

PMX device description file for EtherCat.

Date: 02/2015  |  Version: 1.3  |  Size: 58 KB

Archive including all current files for firmware and PMX WebServer.

To update firmware and WebServer the existing WebServer in the PMX can be used (no additional software or hardware needed).

Note: Please unzip the PMX-firmware download-file to get a .tgz file, which than directly can be uploaded into PMX via the PMX-webserver (menu: Firmware update in the admin level).

Date: 06/2021  |  Version: 4.6  |  Size: 38 MB
関連情報: Release Notes

Software for data acquisition, visualization, analysis and reporting of measurement data for your PC or QuantumX/SomatXR Data Recorder.

Date: 05/2024  |  Version: 5.6.3  |  Size: 473 MB
関連情報: Release Notes

The HBM Device Manager is a service tool to scan the network for available HBM devices.

Date: 12/2019  |  Version: 2.0  |  Size: 7 MB
関連情報: Release Notes

Macro-project containing CAE data for ePLAN Electric P8.

Date: 06/2018  |  Version: 2.00  |  Size: 38 MB

This is a collection of Codesys software achives for typical requirements around PMX.
They show a step-by-step solution up to the running project in Codesys and PMX.

Available languages: german, english.

• PMX Web-visualisation
• PMX in CAN-Master and -Slave mode
• PMX with CAN-modules for temperature and climate measurements
• PMX with Client-Server communication via TCP/IP
• PMX with integrated data-storage on internal memory or USB-stick
• Pressmonitoring
• Windmeter integration
• Extending PMX with ClipX modules
• Test-profiles import via Excel

Legal notice: The examples given are intended to illustrate the solution and integration into PMX.

The examples do not imply any warranty or guarantee.

Date: 05/2019  |  Version: 4.0  |  Size: 284 MB

Archive including all current files for CodeysV3.5SP7 software installation and PMX-Package V3.5.7.10

Date: 03/2016  |  Version: 1.03  |  Size: 635 MB
関連情報: Release Notes
Release Information CODESYS_V3.5 SP7 Patch 4
Features and Improvements V3.5 SP7
CODESYS Quick Start

This example considers a simple test assembly including a Beckhoff PLC CX1020 and a PMX. In this example, consistent (coherent) data are written and read via the EtherCat and shown is a visualization panel. Legal notice: The example given is intended to illustrate the integration of PMX into Beckhoff TwinCat software via EtherCat. This example does not imply any warranty or guarantee.

Date: 04/2014  |  Size: 1 MB

This example considers a simple test assembly including a AlanBradley PLC Compact Logix L24ER and a PMX.

In this example, consistent (coherent) data are written and read via the Ethernet/IP.

Legal notice: The example given is intended to illustrate the integration of PMX into AlanBradley's software RSLogix 5000 via Ethernet/IP.

This example does not imply any warranty or guarantee.

Date: 04/2014  |  Size: 2 MB

This example considers a simple test assembly including a Siemens CPU315-2 PN DP and a PMX.

In this example, consistent (coherent) data are written and read via the Profinet.

Legal notice: The example given is intended to illustrate the integration of PMX into Siemens' Step7 software via Profinet.

This example does not imply any warranty or guarantee.

Date: 04/2014  |  Size: 2 MB

This service-tool visualizes, transfers and stores parameter settings from a PMX parameter-set file in a txt-file. Legal notice: The tool do not imply any warranty or guarantee

Date: 05/2019  |  Version: 1.3  |  Size: 4 MB

This is a collection of technical application reports for typical requirements around PMX. They show a step-by-step solution up to the running project in PMX.
Available languages: German, English and French.

• PMX with Codesys and Codesys WebVisualisation
• PMX as CANmaster and CANslave (read/write CAN messages)
• PMX with IEPE-sensors, T40 or T210 torque-sensors, Piezoelectrical-sensors
• Read sensor signals via CAN, e.g. torque/speed (T12), temperature, climate
• PMX with calculated channels:
  • Event-counter, X-borders, tolerance-band, tolerance-windows, result-force
  • Mechanical work, stress-analysis
  • Combined trigger output
  • 6x6 Matrix-compensation (noise reduction for Multi-Component sensors)
  • PID-regulator, PT100-measurement
  • Torsional Vibration with T40/T12/T10 and CASMA-filter
• PMX integration in a PC-network (Windows or Linux)
  • Using the PMX dotNET-API
  • Using the PMX command-set under LabView
  • Using PMX together with catman for DAQ and Cloud and PowerBI applications
• PMX integration in an automation-network
  • EtherCat and TwinCAT(Beckhoff)
  • ProfiNet (Isonchronus-Real-Time (IRT) and Simatic-manager (TIA-portal, Siemens)
  • Ethernet/IP and RSLogix (Rockwell Automation)
• PMX with internal Dats-Storage or on USB-Stick
• PMX with internal Object-Dictionary and device-to-device communication

Legal notice: The examples given are intended to illustrate the solution and integration into PMX.
The examples do not imply any warranty or guarantee.
